4G Controller UC3x

The UC34xx series is a smart controller product with an embedded 4G cellular modem. The intelligent software and ultra-compact portable form factor design make it an ideal solution for a variety of industrial applications like field device monitoring, remote controlling and data acquisition.

  • Variant

SG$ 192.64

This combination does not exist.

Lead Time : 2.0 weeks

Add to Cart Get Best Price

The UC34xx series is a smart controller product with an embedded 4G cellular modem. The intelligent software and ultra-compact portable form factor design make it an ideal solution for a variety of industrial applications like field device monitoring, remote controlling and data acquisition.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Milesight

At Milesight IoT, we are passionate about the connectivity of “things” to the cloud. We leverage the value of the top trending technologies that transform the world we live in and are committed to our partners who share the same passion.



More details

Overview

The UC34xx series is a smart controller product with an embedded 4G cellular modem. The intelligent software and ultra-compact portable form factor design make it an ideal solution for a variety of industrial applications like field device monitoring, remote controlling and data acquisition.

Feature


  • Easy configuration by USB and Milesight IoT Cloud

  • 2 serial interfaces (1 RS232, 1 RS485) with 1 alarm input and 1 relay output

  • Collect data from Modbus slave device

  • Customizable conditions & programmable actions

  • Integrate legacy serial and I/O devices into cloud

  • Hundreds of combinations of trigger conditions and actions

  • Support global 4G LTE networks

  • Execute actions by triggered conditions autonomously

  • Transmit data to AWS, private UDP/TCP server or MQTT broker

Specifications for 4G Controller UC3x

Variant 1 * RS232 + 1 * RS485 1 * Digital Input 1 * Relay Output or 2 * Analog Input 1 * Digital Input 1 * Relay Output or 2 * Digital Input 2 * Relay Output
This is a preview of the recently viewed products by the user.
Once the user has seen at least one product this snippet will be visible.

Recently viewed Products


SPECIFICATIONS:

Cellular Interface
Connector1 × 50 Ω SMA (Center PIN: SMA Female)
SIMMicro SIM (Inside the device)
Configuration Interface
Port1 × TTL Intraface
Baud Rate115200bps
IO
ConnectorTerminal block
Digital Inputs2 x Opto-isolated Digital Inputs.
Can accept any DC signals of any types, including:
➢ Dry Contacts
➢ DC Voltage (3-24V)
Digital Outputs2 x SPDT Relay Contact Rating:
3 Amp DC (Max: 30 V) or 3 Amp AC (Max: 250 V)
Power Supply
ConnectorTerminal block
Input Voltage5-24V DC (Standard adapter: DC 12V/0.5A)
Physical Characteristics
Ingress ProtectionIP30
Dimensions79 x 60 x 24 mm (3.11 x 2.36 x 0.94 in)
MountingDesktop or Wall Mounting
Others
LED Indicators1 × STATUS, 1 × ACT
Built-inWatchdog
Operating Temperature-40°C to 70°C
Relative Humidity0% to 95% (non-condensing) at 25ºC/77ºF
