Omni Fiber Glass 440~450MHz 100W antenna
Omni Fiber Glass 440~450MHz 100W antenna
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
Overview
The FG4400 from Laird (formerly Antenex) is a heavy-duty, omni-directional fiberglass base station antenna. It has a collinear design enclosed in high-density fiberglass, which is covered with a protective ultraviolet inhibiting coating.
The radiating elements are tuned for the 440-450 MHz and made from high-efficiency copper and are carefully phased to provide maximum gain in the horizontal plane. The mounting sleeves are tuned to eliminate RF currents from the transmission line, resulting in a cold sleeve allowing great freedom in mounting. This high-quality and well-focused beam provides the highest gain and best efficiency.
Features
- Frequency: 440-450 MHz
- Gain: Unity/ 2.15 dBi
- Length: 26 inches
- 100% tested on a network analyzer before shipping to assure the best performance.
- Special UV Treated - stands up to the sun over years of service.
- Durable gold-anodized sleeve and cap with N Female connector.
- Five-Year Factory Warranty.
Specifications for Omni Fiber Glass 440~450MHz 100W antenna
| Antenna Gain | 2.15dBi or 5dBi or 3dBi |
Once the user has seen at least one product this snippet will be visible.
Recently viewed Products
The FG4400 from Laird (formerly Antenex) is a heavy-duty, omni-directional fiberglass base station antenna. It has a collinear design enclosed in high-density fiberglass, which is covered with a protective ultraviolet inhibiting coating.
The radiating elements are tuned for the 440-450 MHz and made from high-efficiency copper and are carefully phased to provide maximum gain in the horizontal plane. The mounting sleeves are tuned to eliminate RF currents from the transmission line, resulting in a cold sleeve allowing great freedom in mounting. This high-quality and well-focused beam provides the highest gain and best efficiency.
FEATURES AND BENEFITS:
- Frequency: 440-450 MHz
- Gain: Unity/ 2.15 dBi
- Length: 26 inches
- 100% tested on a network analyzer before shipping to assure the best performance.
- Special UV Treated - stands up to the sun over years of service.
- Durable gold-anodized sleeve and cap with N Female connector.
- Five-Year Factory Warranty.
Specifications
| SKU | FG4400 |
|---|---|
| Manufacturer Part Number | FG4400 |
| Manufacturer | Laird |
| Antenna Category | UHF (380-600 MHz) |
| Working Frequency | 440-450 MHz |
| Gain | Unity/ 2.15 dBi |
| Center Tuned Frequency 1 | 445 MHz |
| Antenna Style | Omnidirectional Basestation Antenna |
| Polarity | Vertical |
| Bands | Single |
| SISO or MIMO | SISO |
| Directional or Omni | Omnidirectional |
| Impedance | 50 |
| VSWR: < X: 1 | 2:01 |
| Horizontal/Azimuth Beamwidth | 360 |
| Height/Length (inches) | 26 |
| Height/Length (mm) | 660.4 |
| Thickness/Diameter (inches) | 1.31 |
| Thickness/Diameter (mm) | 33.27 |
| Weight (lbs) | 1 |
| Weight (grams) | 453.59 |
| Material | Fiberglass |
| Operating Temp (celsius) | (-40) to 85 C |
| Color | White |
| Connector 1 | N-Female |
| OK for Outdoor Use | Yes |
| Vehicular | No |
| Ground Plane Required | No |
| Product Condition | New |
