What Is a PoE Switch and How Does It Work?

Since introduced to the telecommunication field, PoE switches, as a major application of PoE technology, have made great contributions to simultaneous data and power supply over one single Ethernet cable. Nowadays, in the background of the increasing number of IoT projects such as smart cities and intelligent buildings, PoE switches show greater growth potential. This post will demystify PoE switch in a concrete way by clarifying its functions, the benefits and limitations as well as addressing some FAQs about PoE switches.

What Is a PoE Switch and How Does It Work?

What is a PoE switch? PoE switch or power over Ethernet switch is a network switch that applies Power over Ethernet technology. With a PoE network switch, the network connectivity and the power to supply the PD (powered device) can both be efficiently realized over the Ethernet cable. Currently, there are all kinds of PoE network switches filled in the market. Based on the port number, the 8, 12, 24 port PoE switches48 port PoE switches are commonly seen in the market. When turning to the control level over the network, unmanaged and managed PoE switches are available.

How Does PoE Switch Works.jpg

PoE Switch vs Non-PoE Switch: Why You Need the PoE Switch?

The reason why you need power over Ethernet switches will be obvious when comparing PoE switch vs non-PoE switch. As the most basic switch, the non-PoE switch refers to the switch that is not PoE enabled to supply power for end-users over Ethernet, but can only send data to network devices. To acquire PoE, users have to deploy a midspan power sourcing equipment (PSE) like the PoE injector between the switch and PDs. This injector or other midspan PSEs can add electrical power while receiving data signals from the cable connected with the non-PoE switch, and then deliver both data and power to PDs (Learn more about PoE injector from What Is a PoE Injector And How to Use It?). In this application, the injector or other midspan PSEs will also need a wire for power. However, for a gigabit PoE switch application, things will become easier. For a PoE switch, only one power cable for the switch and one network cable to connect PDs are required. Then the PD can be directly plugged into the PoE gigabit switch port for both data transmission and power supply.

PoE Switch vs Non-PoE Switch.jpg

Based on the working mode of PoE vs. non-PoE switch, the PoE switch brings benefits over the following aspects:

Flexibility: Getting rid of the restrictions of non-PoE switches needing additional PSEs and extension cables, the PoE switches gain great flexibility for users’ network cablings. It enables PDs like IP surveillance cameras to be installed based on where it needs to go. Besides, a combination of PoE switch and wireless technology can even make the cable-free environment be possible.

Simplicity: Without the need to consider additional PSEs and installation locations like a non-PoE switch, the PoE switch simplifies the whole network deployment. In addition, good PoE switches also enable simple network management protocol (SNMP), which provides a simpler way to supervise and manage the switch.

Cost-Efficiency: With PoE network switch, there is no need for users to purchase and install additional electrical wires and outlets, which creates significant savings on installation and maintenance costs and time.

However, there are also some limitations on PoE switches you should pay attention to:

Distance Limitation: The distance that PoE switches can transmit over Ethernet is generally up to 100 meters. For those large campuses, restaurants, and enterprises deploying PoE, the 100-meter distance limitation is a challenge. However, there are still methods to extend PoE range—devices such as power extenders or powered fiber cables. For more information, refer to Powered Fiber Cables: Solution for Extending POE.

Power: If you require high power over PoE networks, you are bound to make sure the power capacity of your PoE switches meets your needs because there is a power limitation based on the PoE standards and PoE Wattage.

Frequently Asked Questions About the PoE Switch

1. Do I Need Special Cables for the PoE Switches?

No. Generally, the Ethernet cables that should be used for PoE switches only depend on the data rate of the PoE port, for example, 10/100M can use Cat3 or better cables; 1000M needs Cat5/Cat5e/Cat6 cables. When you're able to deploy 2.5G/5G/10G PoE devices in the future, you may need Cat6a or better cables. But you can never be wrong to buy good quality Ethernet cables made of oxygen-free copper.

2. Active PoE Switch vs Passive PoE Switch: Should I Choose Active or Passive Poe Switches?

Active PoE switch complies with standard PoE, thus it is also referred to as standard PoE switch. On the contrary, passive PoE switch does not adhere to any IEEE standard. Active PoE switches and passive PoE switches hold their differences in multiple aspects such as PoE power supply pinout, Ethernet support, etc. If you are wondering which PoE switch to choose and you take safety as the first thing, you’d better choose active PoE switch; but if you have a tight budget, you can give a though to a passive one. For more related information, see Active vs. Passive PoE Switch: Which Should We Choose?

3. Can a Computer or Other Non-PoE Devices be Connected to the PoE Switch? And Will a PoE Switch Damage Non-PoE Devices?

The answer depends on your PoE network switch type. Please make sure you use an active PoE switch rather than a passive PoE switch. As mentioned in the last question, active PoE switch is superior to passive PoE switch in safety. Active PoE switches have auto-sensing PoE ports and they can detect whether the connected device is a PoE device or not. When the PoE ports are connected with non-PoE devices like computers or laptops, the PoE switch will detect it as not having PoE capability and interact with it as if it were a regular switch. Then it will just use the data communications features of the port instead of supplying power. Passive PoE switches, however, always send electric current out over the Ethernet cable at a certain voltage regardless of whether the terminal device supports PoE or not. Therefore they may burn out computers and other non-PoE devices. Luckily, PoE switches in the market are basically active types. But passive PoE switches are still supplied by some vendors.

4. Can I Connect a PoE Switch to Another PoE Switch?

Yes, you can. Power is supplied by the PSE to PD only when it detects that the device is capable of handling the power. Since the two PoE switches both function as PSEs, they will just do data communications.

5. PoE Switch vs. PoE+ Switch: What’s the Difference?

The main difference between the PoE network switch and PoE+ switch lies in the electrical power that each can carry or supply to the connected PoE PD. The max. PoE power consumption provided over Cat5 cabling is 15.4 watts for PoE PSE and 30 watts for PoE+ PSE. While the max. power received by PD is 12.95 watts for PoE PD and 25.5 watts for PoE+ PD. Here comes a new PoE++ switch type supporting higher max. power for PSE and PD than PoE and PoE+ switch. More information is in PoE vs PoE+ vs PoE++ Switch: How to Choose?

6. PoE Managed vs. Unmanaged Switch: What’s the Difference?

The managed PoE switch is a switch that allows access to one or more interfaces for the purpose of configuration or management, such as Spanning Tree Protocol (STP), port speed, VLANs, etc. It can give you more control over your LAN traffic and offer advanced features to control that traffic. On the contrary, the PoE unmanaged switch just simply allows Ethernet devices to communicate with one another, such as a PC or network printer. It is pre-equipped with a fixed configuration and disallows any changes to this configuration.

7. How Can I Extend the Maximum Distance of PoE?

Devices such as PoE extenders and media converters can be used in the PoE link to extend PoE.
