LSUM PCB Types series Ultracapacitor Module

PCB types Ultracapacitor Module

  • Ultracapacitor capacity
  • Ultracapacitor Rating voltage

SG$ 140.92

This combination does not exist.

Lead Time : 2.0 weeks

Add to Cart Get Best Price

PCB types Ultracapacitor Module


Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days


LS Materials

LS Mtron Ultracapacitors is on the leading edge of a new paradigm in global energy storage. LS Ultracapacitors (LSUC®) and LS Ultracapacitor Module (LSUM®) products are highly efficient. They are the best choices for customers ranging from small electric products to large railroad systems, and will be established as smart solutions in renewable energy, automobiles and electric power. LS Ultracapacitor energy storage devices are positioned between conventional electrolytic capacitors and rechargeable batteries. LS Ultracapacitors feature high power, high energy, reliability and long life which enables use in a variety of applications such as back-up power, auxiliary power, instantaneous power compensation and peak power compensation.

Do something

Overview

LS Ultracapacitor energy storage devices are positioned between conventional electrolytic capacitors and rechargeable batteries. LS Ultracapacitors are optimized for the highest performance with the lowest resistance possible. They feature high power, high energy, reliability and long life which enables use in a variety of applications such as back­up power, auxiliary power, instantaneous power compensation and peak power compensation.


Features

High power performance compared to batteries

High energy performance vs electrolytic capacitors

Low ESR and high power vs. competing ultracapacitors

Robust design for improved long term reliability

Environmentally friendly

Maintenance­ free

Wide operating temperature range (-40℃ to +65℃)


Specifications for LSUM PCB Types series Ultracapacitor Module

Super cap
Ultracapacitor capacity 58F or 5.8F or 4.1F
Uncategorized
Ultracapacitor Rating voltage 16.8V or 168V or 403.2V
This is a preview of the recently viewed products by the user.
Once the user has seen at least one product this snippet will be visible.

Recently viewed Products


Description

LS Ultracapacitor energy storage devices are positioned between conventional electrolytic capacitors and rechargeable batteries. LS Ultracapacitors are optimized for the highest performance with the lowest resistance possible. They feature high power, high energy, reliability and long life which enables use in a variety of applications such as back­up power, auxiliary power, instantaneous power compensation and peak power compensation.


Features

  • High power performance compared to batteries

  • High energy performance vs electrolytic capacitors

  • Low ESR and high power vs. competing ultracapacitors

  • Robust design for improved long term reliability

  • Environmentally friendly

  • Maintenance­ free

  • Wide operating temperature range (-40℃ to +65℃)

Rated Voltage:168V
Capacitance:5.8F
Capacitance Tolerance:0% / +20%
Cell Configuration:Radial Cell
Operating Temperature:-40 ~ 65 °C
Storage Temperature:-40 ~ 70 °C
Transport Class:Approved for shipping as non-hazardous non-spillable - per IATA Special Provision A67 and 49 CFR
Resistance (DC):240mΩ

Maximum Current:200 A
Leakage Current:<25 mA
Energy Density:3.5 Wh/kg
Maximum Stored Energy:22.7 Wh
Length:23.5 CM
Width:36.7 CM
Height:7.9 CM
Weight:6.5 KG
Shelf Life:After 1500 hours storage at +65 o C without load shall meet specification of endurance
Calendar Life:After 1500 hours application of Rated voltage .DC at 65 ℃ , the capacitor shall meet the following limits.
Cycle Life:After 1,000,000 cycles between rated voltage to half rated voltage at +25 oC
