RA0710 Wireless Water Turbidity Sensor

RA0701 is a wireless communication device that detects the carbon monoxide content in ambient air. RA0701 can detect the concentration of CO in the air.

Class
Frequency band
Power type
Sleep Power consumption
Rx Sensitivity
Sensor Measurement Range
TX Power
Chipset
Sensors

SG$ 2,431.39

This combination does not exist.

Lead Time : 5.0 weeks

Add to Cart Get Best Price

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Netvox

Netvox pioneers in the development and manufacture of Wireless Sensor Network applications based on LoRaWAN and Zigbee Pro Home Automation profile open standard. Since 2005, we have developed over 200 LoRaWAN devices and 250 Zigbee devices that are based on worldwide standards to work with existing systems.

There are more than 70 items in our LoRaWAN magnetic-mounted R718 series that comes with an IP 65/67 housing, and most of them are battery powered with long battery life. For example, the battery life of our Temperature and Humidity Sensor for Low Temperature Environment R718A is more than 5 years based on 25℃, 15-minute report interval, 20dBm Tx power and SF=10.

FIND OUT MORE

Overview

The RA0710 is connected to the ZS-206 integrated online turbidity sensor, and the ZS-206 is designed and manufactured using the principle of scattered light turbidity measurement. The LoRa module of the RA0710 communicates with the turbidity sensor in the form of RS485 communication to obtain the current turbidity signal value and display it through the wireless gateway.

Features

Apply SX1276 wireless communication module
DC 12V adapter power supply
Turbidity detection
LoRaWAN™ Class A compatible
Frequency Hopping Spread Spectrum (FHSS)
Configuration parameters can be configured through a third-party software platform
Applicable to third-party platforms: Actility / ThingPark, TTN, MyDevices / Cayenne

Specifications for RA0710 Wireless Water Turbidity Sensor

Frequency band	AS923 or AU915 or EU868 or US915
Class	Class A
Power type	DC12V/1A
Sleep Power consumption	50mA
Rx Sensitivity	-136dBm
Sensor Measurement Range	0-1000NTU
TX Power	16dBm
Chipset	SX1276
Sensors	Tubidity+Temperature

RA0710 NETVOX WIRELESS LORAWAN TURBIDITY SENSOR

The Netvox RA0710 is connected to the ZS-206 integrated online turbidity sensor. The ZS-206 is designed and manufactured using the principle of scattered light turbidity measurement. The LoRaWAN module of the RA0710 communicates with the turbidity sensor via RS485 communication to obtain the current turbidity signal value and display it through the wireless gateway. The communication is fully compatible with LoRaWAN Protocol (Class A).

FEATURES:

Wireless Range of 10 Km
LoRaWAN™ Class A Compatible
Frequency Hopping Spread Spectrum (FHSS)
Improved Interference Immunity
Improved Power Management For Longer Battery Life
Encrypt-RF™ Security (Diffie-Hellman Key Exchange + AES-128 CBC For Sensor Data Messages)
Battery Life*2:
⁻ 5 Years
(Conditions: Ambient Temperature 25 °C, 20 Triggers/Day, Txpower = 20dBm, LoRa Spreading Factor SF = 10)
Over-The-Air Updates
Third-Party Online Wireless Sensor Monitoring And Notification System To Configure Sensors, View Data And Set Alerts Via SMS Text And Email (Optional)
Available Third-Party Platform: Actility/ThingPark, TTN, MyDevices/Cayenne

Electric:

Power Supply Power Supply	DC Power Supply, DC12V/1A
Operating Current 1	50mA (No RF Signal Emission)
Operating Current 2	90mA (With RF Signal Emission)

Frequency:

TX Power	19dBm±1dBm
Rx Sensitivity	-136dBm (LoRa，Spreading Factor=12，Bit Rate=293bps ) -121dBm (FSK,Frequency Deviation=5kHz, Bit Rate=1.2kbps)
Antenna Type	Build-In Antenna
Communication Range	10 Km (Line-Of-Sight, The Actual Transmission Distance Depends On The Environment)
Data Transfer Rate	0.3kbps～50kbps
Spread Technique	LoRa/FSK
Available Frequency	EU863-870，US902-928，AU915-928， KR920-923，AS923，CN470-510 Configured Before Shipment
