4-port USB 2.0 Ethernet LAN Extender System

The Ranger 2304GE-LAN comes with the following items in the box: Remote extender (REX) Local extender (LEX) 1 x USB 2.0 Type A to Type B cable 100-240V power adapter Country specific power cord Quick start guide *Please be aware that the Ranger 2304GE-LAN does NOT come with a CAT5e cable.

  • USB standard
  • Distance
  • Power Adapter
  • USB ports
  • Transmission Media
  • Power Adapter Location

SG$ 572.73

This combination does not exist.

Lead Time : 20.0 weeks

Add to Cart Get Best Price

The Ranger 2304GE-LAN comes with the following items in the box:

Remote extender (REX)
Local extender (LEX)
1 x USB 2.0 Type A to Type B cable
100-240V power adapter
Country specific power cord
Quick start guide
*Please be aware that the Ranger 2304GE-LAN does NOT come with a CAT5e cable.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Icron

Icron is a Maxim Integrated brand, as well as a leading global developer and manufacturer of high-performance USB and video extension solutions for commercial and industrial markets including Medical, Military, Industrial Automation, Machine Vision, ProAV, Education, and Mining/Exploration.



FIND OUT MORE



Overview

Overview

The USB 2.0 Ranger® 2304GE-LAN allows users to extend USB 2.0/1.1 connections over a GigE LAN or single CAT 5e/6/7 cable up to 100m in point-to-point fashion. Extending over LAN saves on installation time and provides IT visibility.

This 4-port USB 2.0 LAN extender supports data rates at up to 480 Mbps and is plug and play – no software drivers required – for all major operating systems: Windows®, macOSTM, and Linux®

Additionally, this ExtremeUSB® based 4-port USB 2.0 LAN extender system is FCC/CE Class B certified and ideal for use with all USB peripherals including: keyboards, mice, interactive white boards, flash drives, hard drives, audio devices, web cameras and any other USB 2.0 or 1.1 device.

Features

  • Extends USB as direct connect or through 100Mbps or 1000Mbps LANs
  • Extends USB 2.0 and 1.1 (both low-speed and full-speed) devices
  • Operates with USB 3.0, 2.0 and 1.1 hosts
  • Supports all USB compliant peripherals (including isochronous devices, such as webcams or audio devices) up to 480 Mbps
  • Uses a standard solid core CAT 5e cable for easy installation or existing LAN infrastructure
  • Pre-paired networked configuration for simple installation
  • Number of devices can be increased using additional USB hubs
  • FCC Class B
  • Rugged metal enclosure
  • ExtremeUSB® suite of features:
    • Transparent USB extension
    • True plug and play; no software drivers required
    • Works with all major operating systems: Windows®, OS X® and Linux®

Specifications for 4-port USB 2.0 Ethernet LAN Extender System

USB Extender
USB standard USB 2.0
Distance 100m
Uncategorized
Power Adapter Europe or Australia or Japan or Unit Kingdom
USB ports 4 USB ports
Transmission Media CAT 5e/6/7 or Local Area Network
Power Adapter Location REX
This is a preview of the recently viewed products by the user.
Once the user has seen at least one product this snippet will be visible.

Recently viewed Products


Overview

The USB 2.0 Ranger® 2304GE-LAN allows users to extend USB 2.0/1.1 connections over a GigE LAN or single CAT 5e/6/7 cable up to 100m in point-to-point fashion. Extending over LAN saves on installation time and provides IT visibility.

This 4-port USB 2.0 LAN extender supports data rates at up to 480 Mbps and is plug and play – no software drivers required – for all major operating systems: Windows®, macOSTM, and Linux®

Additionally, this ExtremeUSB® based 4-port USB 2.0 LAN extender system is FCC/CE Class B certified and ideal for use with all USB peripherals including: keyboards, mice, interactive white boards, flash drives, hard drives, audio devices, web cameras and any other USB 2.0 or 1.1 device.

Features

  • Extends USB as direct connect or through 100Mbps or 1000Mbps LANs
  • Extends USB 2.0 and 1.1 (both low-speed and full-speed) devices
  • Operates with USB 3.0, 2.0 and 1.1 hosts
  • Supports all USB compliant peripherals (including isochronous devices, such as webcams or audio devices) up to 480 Mbps
  • Uses a standard solid core CAT 5e cable for easy installation or existing LAN infrastructure
  • Pre-paired networked configuration for simple installation
  • Number of devices can be increased using additional USB hubs
  • FCC Class B
  • Rugged metal enclosure
  • ExtremeUSB® suite of features:
    • Transparent USB extension
    • True plug and play; no software drivers required
    • Works with all major operating systems: Windows®, OS X® and Linux®

Specifications

  • Direct Connect Range: Up to 100m (330 ft) over solid core CAT 5e/6/7 or better
  • Network Connect Range: Up to 100m (330 ft) between switches over solid core CAT 5e/6/7
  • USB Device Support:
    • Traffic Types: All USB 2.0 and 1.1
    • Device Types: All USB 2.0 and 1.1 devices
  • LEX unit USB connector: 1 x USB Type B Receptacle
  • LEX unit Link connector: 1 x RJ45
  • REX unit Link connector: 1 x RJ45
  • REX unit USB connector: 4 x USB Type A Receptacles
  • Maximum USB devices supported: 30 USB devices or hubs
  • Power Supply: 100-240V AC input, 24V DC Output
  • Available current: Up to 600mA at each USB port concurrently
  • LEX and REX unit dimensions: 100mm x 76mm x 26mm (3.9” x 3.0” x 1.0”)
  • Operating temperature range: 0°C to 50°C ( 32°F to 122°F)
  • Total system shipping weight: 870 grams (1.9 lbs.)
  • Regulatory testing: FCC (Class B), CE (Class B), RoHS2 (CE)
  • Warranty: 2 years

Applications

The Ranger 2304GE-LAN system extends USB devices point-to-point with CAT 5e/6/7 cabling or can leverage existing network infrastructure, and is ideally suited for the following applications:
