EM500-UDL Ultra-Sonic water measurement

EM500-UDL provides highly accurate distance measurement for a variety of applications in harsh environments like flood monitoring, waster water management, fill level monitoring in grains or fertilizer. The measurement is based on ultrasonic waves transmitted and reflected back from nearby objects.

Configuration Interface
Cable length
Frequency band
Sensor
Waterproof
Power type
Sensor Measurement Range
Battery Capacity
Payload Format

SG$ 580.44

This combination does not exist.

Lead Time : 3.0 weeks

Add to Cart Get Best Price

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Milesight

At Milesight IoT, we are passionate about the connectivity of “things” to the cloud. We leverage the value of the top trending technologies that transform the world we live in and are committed to our partners who share the same passion.

FIND OUT MORE

Overview

EM500-UDL provides highly accurate distance measurement for a variety of applications in harsh environments like flood monitoring, wastewater management, fill level monitoring in grains or fertilizer. The measurement is based on ultrasonic waves transmitted and reflected back from nearby objects.

Features

Measurement ranges between 0.3m and 10m
Measure very small containers or openings
Suitable for measuring benign and chemical mediums
Suitable for non-contact detection for any corrosive liquid chemicals or combustibles
Built-in 19000 mAh high-capacity battery can be used for 10-years
IP66 rated protective case (IP67 on request)
LoRaWAN wireless transmission
Configure the device via NFC
Monitor your data in the office or on the go with Milesight IoT Cloud.

Specifications for EM500-UDL Ultra-Sonic water measurement

LoRaWAN
Configuration Interface	NFC
Uncategorized
Frequency band	AS923 or AU915 or KR920 or US915
Sensor Measurement Range	0.3m~5m or 0.5m~10m
Cable length	NA
Sensor	Ultrasonic
Waterproof	IP66
Power type	Battery
Battery Capacity	19000mAh
Payload Format	Caynne

EM500 Series User Guide
Release date: December 10, 2020
Download
EM500-UDL Datasheet
Release date: December 10, 2020
Download

LoRaWAN®	Frequency	AU915/AS923
	Tx Power	20dBm
	Sensitivity	-147dBm @300bps
	Mode	OTAA/ABP Class A
Measurement	Range	EM500-UDL-W050: 0.3-5m
		EM500-UDL-W100: 0.5-10m
		(Customizable for snow level detection usage)
	Resolution	1 mm
	Accuracy	±1%
Physical Characteristics	Power Supply	19000 mAh Li-SOCL2
	Operating Temperature	-30°C to +65°C
	Ingress Protection	IP66 (IP67 as required)
	Dimension	156.1 × 71 × 69.5 mm
	Mounting	DIN rail, wall, pole mounting
