There are 3 series of products to suit your needs: DMF up to 5.5V, with very low ESR, down to 40m? to meet your power needs, and up to1F for energy storage; DMT which is a very long life part that can operate up to 85°C and up to 4.2V – ideal if paired with a Li-ion battery, or a 3.6V Lithium Thionyl Chloride battery in a set and forget long life, 10 – 15 year application such as a smart meter, building or industrial sensor; and DMH which is ultra-thin, 20mm x 20mm x 0.4mm, 4.5V, ideal for wearables, smart cards, applications where sleek design is key.
Ultra-thin prismatic cells and modules: Ideal for use in space-constrained devices
Exceptional power density (up to 128 kW/litre), with best-in-class ESR (from 15 m?)
High energy density (up to 1.9 Wh/litre), offering high Capacitance in small cells
True, continuous operating voltage of up to 2.75V/cell (H series; 2.9V peak)
High temperature rating (H series; 85°C maximum)
Excellent low temperature performance (G series; ~2x nominal ESR at -30°C)
Very low leakage current (<1 µA) and ultra-low minimum charge current (<20 µA)
Virtually unlimited charge-discharge cycle life
Excellent frequency response (CEFFECTIVE)
RoHS and REACH compliant, Lead-free, Halogen-free and Conflict metal-free
UL-810 and ISO 9001:2015 certified
