1. Products
  2. R712 -Wireless Outdoor Temperature Humidity Sensor
SGD Pricelist
Manufacturing Company :

R712 -Wireless Outdoor Temperature Humidity Sensor

R711A is mainly used to detect the temperature of indoor air. It transmits the collected data to other devices for display through the wireless network communication module. The device conforms to the LoRa protocol standard.

  • Configuration Interface
  • Waterproof
  • Class
  • Frequency band
  • Power type
  • Sleep Power consumption
  • Rx Sensitivity
  • Sensor Measurement Range
  • TX Power
  • Chipset
  • Certification
  • Sensors

SG$ 165.75

This combination does not exist.

Lead Time : 6.0 weeks

Add to Cart Get Best Price

R711A is mainly used to detect the temperature of indoor air. It transmits the collected data to other devices for display through the wireless network communication module. The device conforms to the LoRa protocol standard.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Netvox

Netvox pioneers in the development and manufacture of Wireless Sensor Network applications based on LoRaWAN and Zigbee Pro Home Automation profile open standard.  Since 2005, we have developed over 200 LoRaWAN devices and 250 Zigbee devices that are based on worldwide standards to work with existing systems.

There are more than 70 items in our LoRaWAN magnetic-mounted R718 series that comes with an IP 65/67 housing, and most of them are battery powered with long battery life.  For example, the battery life of our Temperature and Humidity Sensor for Low Temperature Environment R718A is more than 5 years based on 25℃, 15-minute report interval, 20dBm Tx power and SF=10.


FIND OUT MORE

Overview

R712 is a long-range wireless temperature and humidity device based on the LoRaWAN™ open protocol (Class A). R712 carries a splash-proof housing, and it is mainly used to detect the outdoor air temperature and humidity. It collects data over LoRa® network and sends it to devices to be shown.



    Features

    Compatible with LoRaWAN™ protocol
    2 x 1.5V AA Alkaline battery
    Reports battery voltage, outdoor air temperature and humidity
    Easy set up and installation



              Specifications for R712 -Wireless Outdoor Temperature Humidity Sensor

              LoRaWAN
              Configuration Interface UART
              Uncategorized
              Frequency band AS923 or AU915 or EU868 or US915
              Waterproof IP67
              Class Class A
              Power type 2 x 1.5V AA batteries
              Sleep Power consumption 12uA
              Rx Sensitivity -136dBm
              Sensor Measurement Range -20°C ~ 55°C
              TX Power 16dBm
              Chipset SX1276
              Certification FCC/CE/TELEC/LORAWAN
              Sensors Temperature/Humidity
              This is a preview of the recently viewed products by the user.
              Once the user has seen at least one product this snippet will be visible.

              Recently viewed Products


              Electric:

              Input power

              2 x 1.5V AA batteries

              operating voltage

              DC 2.1V

              Standby current

              12uA/3V

              Transmitting current (max)

              120mA/3.6V

              Receiving current (max)

              11mA/3.6V


              Frequency:

              Physical:

              Dimension

              L:222mm*W:130mm*H:195mm

              Working Temp

              -10°C － 50°C

              Storage Temp

              -40°C － 85°C

              Temperature Detecting Range

              -10℃～50℃

              Temperature Accuracy

              ±0.5℃ @25℃
